Gas - Diesel Dryer
Basic information:
Application: The dryer can be used to bake all kinds of puffed food, pet food, fish feed, textured protein, and various nuts including peanuts, melon seeds, and dried jujube.
Capacity: 500kg/h-1000kg/h
Certification: CE, ISO9001, SGS
Delivery Time: Around 15 days
Description
Features:
1.Dryer is compact, has a small dry area and a large superficial area. It also features a small scale of heat elimination and high thermal efficiency.
2.Mesh belt conveyors and thermal insulation boards all use stainless steel material, making the equipment clean and sanitary.
3.The speed of the mesh belt conveyor is adjustable. The drying period
for food in the oven can be adjusted.
4.The automatic temperature control system makes it possible to set the temperature according to your needs.
Technical Parameters:
Diesel oil dryer
Model
Oil Consumption
Heating Temperature
Output
Dimension
RYKX-5-8
7-9L/h
~180℃
500kg/h
9920x1300x2200
RYKX-7-8
8-10L/h
~180℃
700kg/h
9920x1300x2610
RYKX-7-11
12-15L/h
~180℃
1000kg/h
12770x1300x2610
Gas dryer
| Model | Gas Consumption | Heating Temperature | Output | Dimension |
| RQKX-5-8 | 6-8m³/h | ~180℃ | 500kg/h | 9920x1300x2200 |
| RQKX-7-8 | 7-9m³/h | ~180℃ | 700kg/h | 9920x1300x2610 |
| RQKX-7-11 | 10-15m³/h | ~180℃ | 1000kg/h | 12770x1300x2610 |
Food and Feed Samples:
